3.3. I 2 C Isolator Design Constraints
Table 13 lists the I 2 C isolator design constraints.
Table 13. Design Constraints
Design Constraint
To prevent the latch condition, the
isolator output low level must be
greater than the isolator input low
level.
Data Sheet Values
Isolator V OL 0.7 V typical
Isolator V IL 0.5 V typical
Input/Output Logic Low Level
Difference
Effect of Bus Pull-up Strength
and Temperature
This is normally guaranteed by the
isolator data sheet. However, if the
pull up strength is too weak, the out-
put low voltage will fall and can get
too close to the input low logic level.
? VSDA1, ? VSCL1 = 50 mV minimum These track over temperature.
If the pull up strength is too large,
The bus output low must be less
than the isolator input low logic
level.
Bus V OL = 0.4 V maximum
Isolator V IL = 0.41 V minimum
the devices on the bus might not pull
the voltage below the input low
range. These have opposite tem-
perature coefficients. Worst case is
hot temperature.
If the pull up strength is too large,
the isolator might not pull below the
Bus V IL 0.3 x V DD = 1.0 V minimum for bus input low voltage.
The isolator output low must be
V DD = 3.3 V
Si8600/02/05/06 Vol: –1.8 mV/C
less than the bus input low.
Isolator V OL = 0.8 V maximum
CMOS buffer: –0.6 mV/C
This provides some temperature
tracking, but worst case is cold tem-
perature.
3.4. I 2 C Isolator Design Considerations
The first step in applying an I 2 C isolator is to choose which side of the bus will be connected to the isolator A side.
Ideally, it should be the side which:
1. Is compatible with the range of bus pull up specified by the manufacturer. For example, the Si8600/02/05/06
isolators are normally used with a pull up of 0.5 mA to 3 mA.
2. Has the highest input low level for devices on the bus. Some devices may specify an input low of 0.9 V and
other devices might require an input low of 0.3 x Vdd. Assuming a 3.3 V minimum power supply, the side with
an input low of 0.3 x Vdd is the better side because this side has an input low level of 1.0 V.
3. Have devices on the bus that can pull down below the isolator input low level. For example, the Si860x input
level is 0.41 V. As most CMOS devices can pull to within 0.4 V of GND this is generally not an issue.
4. Has the lowest noise. Due to the special logic levels, noise margins can be as low as 50 mV.
